B82.AXDNSAGCSZXKIMXX / VEGABAR 82 - Vega Chile Sales

BRAND	Vega
Product	B82.AXDNSAGCSZXKIMXX / VEGABAR 82
Description	Pressure transmitter with ceramic measuring cell
Internal code	ONR3432012
Weight	0.627
Custom code	90262020
Technical specification	Pressure transmitter with ceramic measuring cell VEGABAR 82 B82. AXDNSAGCSZXKIMXX eID: DE74428201 scope The VEGABAR 82 is a universally applicable pressure transmitter for measuring gases, vapors and liquids. Ingredients such as sand are also lightweight for the abrasion-resistant ceramic measuring cell exercise. The VEGABAR 82 offers maximum reliability and operational safety. The diverse Usability is evident in all industrial sectors. The simple interconnection of sensors VEGABAR series 80 as electronic differential pressure opens up new possibilities for measuring differential pressures. Your benefits - High system availability due to the highest overload and vacuum resistance of the ceramic measuring cell - Measurement down to the last drop through the smallest measuring ranges with high measurement accuracy - Low maintenance and maintenance costs due to wear-free ceramic measuring cell Scope A: Europe Approval X: for explosion-free areas process connection/ material DN: thread G ½, inside G¼, ISO228-1/316L Sealing concept S: single seal Measuring cell seal/ process temperature A: FKM (VP2/A)/-20... +130°C Pressure type G: relative pressure (measurement against atmosphere) Measuring range C: 0... +0.4 bar (0... +40 kPa) Accuracy class S: 0.20% Electronics Z: two-wire 4... 20 mA Optional surge protection: none Additional electronics X: without Housing K: plastic single-chamber Housing type/ Degree of protection I: compact/IP66/IP67; NEMA 4X Cable entry/ M connection: M20x1.5/Cable gland PA black (diameter 5-9 mm), standard PLICSCOM X display/control module: without Certificates X: no Operating Instructions: DE - German Number of operating manuals: 1 Linearization: no Measuring cell type: CERTEC - ceramic measuring cell Factor overload resistance measuring cell: 75,000 Process seal included: Klingersil C-4400 Electronic differential pressure: configuration not suitable Min. process pressure: -0.800 Max. process pressure: 30,000 Customs tariff number (HS code): 90262020

Please Contact Us to Order to offer competitive prices and delivery time for Vega - B82.AXDNSAGCSZXKIMXX / VEGABAR 82 Pressure transmitter with ceramic measuring cell number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Chile Industrial products Market.
