BRAND | Warex |
Product | Type DKZ103 DN 600 |
Description | butterfly valve |
Internal code | ONR4494511 |
Custom code | 84818085 |
Technical specification | Basis: preliminary order 150032/2013 for medium: air Properties: pourable, chemically neutral, not prone to caking Working pressure: 0.5 bar. Max. allowed Working pressure: 1.0 bar (PS) MAWP (Note: MAWP = Ausl. pressure) Operating temp.: 0 °C... +60 °C (Ts) MAWT Ambient temp.: 0 °C... +50 °C (Ta) Explosion protection: no requirement Article number WX2000 installation length 110 mm for clamping between flanges according to EN 1092, PN 6 housing made of silumin Flap disc made of steel/WCB Shafts made of stainless steel 1.4057 or higher quality Shaft sealing by means of O-rings Shaft bearing in brass - bushing sealing collar made of NBR black firmly glued in the housing further attachments: further attachments: Pneumatic rotary actuator RC 265 DA double-acting 1296 Nm required control pressure 6.0 bar Solenoid valve 5/2 way function Norgren 2623077.3037 48 V DC, 1.7 W, IP 65 Namur version Limit switch box with 2 sensors Turck NI 4-M12-AZ 31X NO contact, 20-250 V AC/ 10-300 V DC, IP 67 AC/DC version built into Makrolon housing 175/80/55 and wired to terminal strip |
Discover the superior quality and performance of the Warex Type DKZ103 DN 600 with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Type DKZ103 DN 600 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Type DKZ103 DN 600 :
At Onrion LLC , we offer the Type DKZ103 DN 600 at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the Type DKZ103 DN 600 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
