| BRAND | JSP Industrial-Control |
| Product | T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 |
| Description | Sensor |
| Internal code | ONR4937290 |
| Custom code | 90259000 |
| Technical specification | T1070 … Resistance temperature sensor into thermowell 06 … Temperature sensor 1× Pt100 / 4-wire, sheath material 1.4404 F2 … Accuracy class B according to EN 60751, measuring range -70 to 500 °C J13 … Fitting of the sensor into thermowell, extension piece Ø 14×2,5 mm, material 1.4541 L100 … Nominal immersion of sensor L = 100 mm H3 … Head Al alloy, with high cap for mounting of transmitter with diameter 44 mm, cable outlet M20x1.5 for cable diameter 4 to 12.5 mm, IP 65 S5 … Cold-end of measuring insert with ceramic terminal block diameter 42 mm, embedded pins (according to NAMUR) D3 … Measuring insert diameter D = 6 mm N040 … Extension piece N = 40 mm, Tmax on thread 210 °C P5 … Process connection male thread G1/2" |
Discover the superior quality and performance of the JSP Industrial-Control T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 :
At Onrion LLC , we offer the T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply JSP Industrial-Control products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
