BRAND | Nord |
Product | SK 9042.1AF-132MP/4 TF |
Description | Helical bevel geared motor |
Internal code | ONR4580551 |
Technical specification | Engine speed 1,460 rpm Translation 47.67 Output speed 31,000 rpm Service factor 1.20 Output torque M2 (Nm) 2,338.00 Max. output torque M2 max. (Nm) 2,800.00 Power (kW) 7,500 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 Operating mode S1 Degree of protection motor IP55 Insulation class F Rated current 1 (AMP) 15.70 Rated current 2 (AMP) 9.10 cosine 1 0.77 Type of gearbox M5 Housing type hollow shaft flange B5 Shaft dimension 60H7 Flange diameter (mm) 350 Flange position Flange at B Vent Pressure Vent Shaft seal gear Viton Thermal motor protection PTC thermistor, 3x155°C Circuit type triangle Terminal box position / cable entry 4/III Shaft sealing ring motor FKM (Viton) sealing ring Type of lubricant Without lubricant Class oil CLP 220 Lubricant quantity (l) 6,500 Prescribed lubricant mineral oil ISO VG 220 Shade 7031 blue-grey Paint type solid paint Painting specification old painting 2 Painting instructions basic (2) CE Logo Yes CCC logo no Mexico Certificate NOM No UL no CSA no DoE CC No CSA ev no High Rendimento No Korea Energy Label No |
Discover the superior quality and performance of the Nord SK 9042.1AF-132MP/4 TF with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SK 9042.1AF-132MP/4 TF is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SK 9042.1AF-132MP/4 TF :
At Onrion LLC , we offer the SK 9042.1AF-132MP/4 TF at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the SK 9042.1AF-132MP/4 TF ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nord products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
