BRAND | GSR |
Product | G072.000251.010.006.010 |
Internal code | ONR4803544 |
Custom code | 84818079 |
Technical specification | Reference A72321002.032XX for connection to 24V DC consists of: 072.000251 3/2 way solenoid valve Product name: A7232/1002/.032 Control type: directly controlled, differential pressure min. 0 bar Construction: seat valve with nipple seal Function: NC - closed without power Connection: G1/8 Seat: 2 mm Pressure: 0 - 11 bar Temperature (medium): -10°C/+80°C Ambient temperature: -10°C/+35°C Viscosity (max.): 22 mm²/sec Medium: liquid, gaseous, neutral Material (housing): Brass 2.0401 Material (in contact with media): Brass 2.0401/stainless steel 1.4104 (AISI 430 F) Seal: FKM Installation: drive in horizontal or upright position B0051.000122 magnetic coil Type: .032 (K0510310) Voltage: 24V DC Dust/water protection: IP65 Power: 11 watts Duty cycle: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040.000043 device plug with LED and diode protection circuit, pay attention to the correct polarity connection! Operating voltage: 24 volts DC max operating current: 8 amps Ambient temperature: -40 to +90°C Cable screw connection: PG 11 connectable cables: Ø4.5-11mm max.1.5mm² LED color: red |
Please Contact Us to Order to offer competitive prices and delivery time for GSR - G072.000251.010.006.010 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Chile Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
