BRAND | HIMMEL |
Product | CAF10-G56M4 |
Description | worm gear motor |
Internal code | ONR4296103 |
Custom code | 85015100 |
Technical specification | Product No. 2010001117 Dimension sheet: CAF14 Gear Type/Type: HIMMEL® worm gear motor/HIMMEL® -worm gear Transmission Type/Type: CAF10-G56M4 Dimension image/Dimension sheet: CAF14 Output speed/ Output speed [rpm; 1/rpm]: 13.20//16.00 Translation/ ratio [i]: 102.15 Color/colour: RAL 7011 iron grey/Iron grey Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Coating thickness/ paint layer thickness [μm]: 60-80 Protection class/protection class: IP54 Design/mounting position: H-04-A Output torque/output torque [Nm]: 49.4//40.9 Direction of rotation/direction of rotation: right/right [CW] Output shaft gearbox/ Output shaft [mm; inch]: H20x124.50 Gearbox/Bearing: associated bearings/assigned bearings Type of oil/Oil type: CLP PG 460 Synth.oil Amount of oil/Oil quantity [l]: 0.15 Flange diameter/flange diameter [mm; inch]: 120 Wave material/ Shaft material: C45 Gearbox/Sealing: Shaft Seal (WDR)/Shaft Seal Ring Electrical version/Electrical design: CE Number of poles/poles: 4 Rated frequency/Nominal frequency [Hz]: 50//60 Rated voltage/nominal voltage [V]: 220-240/380-415//220-277/380-480 Circuit/Wiring: S100//S100 (D/Y//D/Y) Rated power/Nominal power [kW]: 0.12//0.12 Motor speed nominal/Motor speed nom. [1/rpm]: 1350//1630 Rated current/Nominal current In [A]: 0.83/0.48//0.80/0.46 cosPHI/cosPHI: 0.66/0.66 KK location/terminal box position: 1A KK version/Terminal box type: plastic/plastic Winding protector/motor protector: without/without Output shaft engine/Output shaft [mm; inch]: V11x24.5 Engine seal/Sealing motor: normal/normal Insulation class/Insulation class: F Operating mode/Duty type: S 3-75% Fan/ Fan: plastic/plastic |
Discover the superior quality and performance of the HIMMEL CAF10-G56M4 with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CAF10-G56M4 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CAF10-G56M4 :
At Onrion LLC , we offer the CAF10-G56M4 at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CAF10-G56M4 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply HIMMEL products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
