BRAND | Analytec |
Product | 35125004 |
Description | Opto small limit switch |
Internal code | ONR4855578 |
Custom code | 85365019 |
Technical specification | 14441447 OLS-C20 M16x1.5 3m PVC SE OLS-C optolectronic liquid limit sensor old Phoenix type: 720.0020SE-59K3P old material no.: 500224 new product number: 35125004 Maximum pressure: 50 bar Temperature, fluid, max.: 135°C Min. fluid temperature: -30°C Process connection: M16 x 1.5 Wrench size: SW 24 Switching direction: switching immersion (SE) (Closer when the level rises) Material stainless steel 1.4571 Any installation position Output: O.C. PNP transistor, short-circuit proof, Current, voltage and power limits Electr. 3 m 3-pin PVC cable connected Operating power: 24 VDC Protection class: IP66 |
Discover the superior quality and performance of the Analytec 35125004 with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 35125004 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 35125004 :
At Onrion LLC , we offer the 35125004 at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 35125004 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Analytec products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
720.0020 SE -> Nachfolger OLS-CBMZ05000135-0301B7FFFFDM3 7PS2Z
oil level sensor,ID. Nr: 178558, 24V
Optoelectronical liquid limit sensor
OPTIC LEVEL TRANSDUCTOR
720.111 300 000.0669 (OR 0689)
ML 25mm, TEMP.: R= -269’C to 400’C PRESSURE.: R= 0-250 BAR GRAPHITE ST ST HOUSING THREADED G1/2A MUST INCLUDE AMPLIFIED BOX SENSOR P/N: 720.160217000.0250, 2.8 VA, 24 VDC
OPTIC LEVEL TRANSDUCTOR
TRANSDUCTOR, TEMP.: R=-65’C to 250’C PRESSURE: R= 0-250 BAR GRAPHITE ST ST HOUSING THREADED G1/2A MUST INCLUDE AMPLIFIED BOX SENSOR P/N: 720.260214000.0250, 2.8 VA, 24 VDC
Switch
OLS-CBMZ05000135-0301B7FFFFDM3 7PS2Z
OLS-C20 - High pressure type Old name: KSR-OPTO.0020SE - 59K3P Optoelectronic Level switch type OLS-C Pressure: 50 bar Temperature, medium, max .: 135 ° C Temperature, medium, min .: -30 ° C Medium: Water Electrical connection: cable PVC Cable length: 3 m Mounting position: any Process Connection Size: M16x1,5 Material: Stainless steel 1.4571 (316Ti) Output: PNP transistor Contact: make contact with rising level Power supply: DC 24 V Protection: IP66 Customs tariff number: 90261089
Optical Limit Switch
Small limit switch
Switch amplifier
level switch top of the product only
Kleingrenzschalter
Optoelectronic Transducer
Optoelectronic level switch
optoelectronic alarm card
