| BRAND | Nuova Fima |
| Product | 1303AF---.ACFE.43M.S10.T32 |
| Description | BOURDON TUBE PRESSURE GAUGE |
| Internal code | ONR2060639 |
| Weight | 1.5 |
| Technical specification | SOLID-FRONT PRESSURE GAUGE, MODEL MGS30. 4.5" (125 MM) CASE DIAMETER. BOTTOM CONNECTION. RANGE 0...16 KG/CM2, 1/2" NPT MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, POLYAMMIDE CASE AND BLOW-OUT DISK, ST. ST. SAFETY CELL, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER WITH MICROMETRIC ADJUSTABLE, ACCURACY ±1,0%, SILICONE OIL FILLING, IP67 PROTECTION DEGREE, SHATTERPROOF AND TEMPERED SAFETY GLASS, ST.ST. RESTRICTOR |
Discover the superior quality and performance of the Nuova Fima 1303AF---.ACFE.43M.S10.T32 with Onrion LLC in Chile . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1303AF---.ACFE.43M.S10.T32 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1303AF---.ACFE.43M.S10.T32 :
At Onrion LLC , we offer the 1303AF---.ACFE.43M.S10.T32 at competitive prices and with the fastest delivery times across Chile . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 1303AF---.ACFE.43M.S10.T32 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nuova Fima products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
(Pressure transmitter with local readout for homogenizer Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA167 Range: 0-600 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with calibration certificate (C01))
CAMERA
Statistische Warennummer: 90262040 Pressure gauge Type: 01.27.1.A.I Execution: Laboratory bourdon tube test gauge Mounting: direct Diameter: DN 250 (10") Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-40 bar Case material: Aluminium, black coated External zero-adjustment High precision movement mounted on ball bearing Dial: Anti-parallax mirror Pointer: balanced, antiparallax knife-edge micrometer, adjustable Window material: Plexiglas Accuracy: Kl. 0,1 Specials: factory test certificat, traceable to international Standard
range 0-250 bar
(version "all stainless steel": DN 63) 1.18.3.DC0/16 BAR.21M
(Pressure gauge Type: 01.M2.3-D-E-0/400 bar-41M-04D.BM2.E Execution: all st.st. bourdon tube pressure gauge MCE18/3/E oil filled with double electric contact Mounting: with front flange diameter: DN 100 Connection: 1/2" BSP back in st.st. AISI 316L Range: 0-400 bar Case material: bayonet-lock case in st.st. AISI 304 window material: Plexiglas contacts: First contact opening, second contact opening on rising pressure, magnetic snap action)
Over pressure protection MP 4/8A in st.st. AISI 316 5.48A.5.41M.41F setting: 3....15 psi process connection : 1/2" BSP male gauge connection: 1/2" BSP female
MGS18 1.18.2.A.E-.AAFB.43M.C40.T32
pressure gauge
1.18.3.A.E.---.DAE7.41M.KCS ALL ST. ST. PRESSURE GAUGE, MODEL MGS18. 4" (100 MM) CASE DIAMETER. BOTTOM CONNECTION., RANGE 0...6 BAR/PSI, 1/2" BSP MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, ST. ST. CASE AND BAYONET RING, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER, ACCURACY ±1,0%, GLYCERINE FILLING, IP67 PROTECTION DEGREE, TEMPERED GLASS WINDOW, ST.ST. RESTRICTOR, MOUNTING WITH DIAPHRAGM SEAL
A 106 GR B carbon steel process connection 1/2" BSP male gauge connection: 1/2" BSP female
o. 3/20800420/10 Flow: 23,000 Nm3 H: 760 mbar
Thermometer, ½” Q: 100 0-150
TB899 (6.TB8.9.9.F.ATFT.43M.7)
BIMETALLIC THERMOMETER
(Thermometer Type: 06.TB.899.G.43M.8.300.T01 Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 300 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: 0/ 100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0 tropicalization)
TB-HW-D-899 / 06.TB.899.G.43M.S8.430
(Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 430 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: -50 / +50°C (nearest available range) Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0)
Thermometer Type: 6.TB.819.E.43M.8.170.0/100°C. Execution: all st.st. bimetal thermometer Mounting: lower connection Diameter: DN 100 Stem: 8 x 170mm in st.st. AISI 316 Connection: 1/2" NPT in st.st. AISI 316L sliding male swivel nut Range: 0/100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0
Pressure switch 1 microswitch Type A, single standard setting range: 6-250 bar cable exit: 1/2" BSP female UNI 6125 process connection: 1/4" NPT female
MANOMETER
transmitter
8.SMA.AAFV.41M.1.FPM (DMU-S-D-000865)
Pressure transmitter with flush diaphragm
6.TB8.9.9.F.ATF2.43M.7.E65.T32.T25
Bimetal Thermometer
PRESSURE GAUGE
2.15.1.A.E.---.AAFB.43M.QPL.SQ1.C
Differential Pressure Gauge
